Miniature Steam Pty Ltd

4045 3" Horizontal Boiler Steam Plant - fit your own engine.

4045 3" Horizontal Boiler Steam Plant - fit your own engine.

Regular price €659,95 EUR
Regular price Sale price €659,95 EUR
Sale Sold out
Tax included. Shipping calculated at checkout.

A 10% GST is included in these pages for Australian Customers. Prices for International Visitors are not taxed when accessing their own currency.

Custom Steam Plants – fit your own engine.
These are steam plants designed to allow a client to select a fully assembled plant minus the engine. To assist with selection we have noted the MSM engines we would recommend for this plant if we were asked to: Tyne, Avon Clyde Echuca, Pevensey. Also the TVR1 that is not our engine

Components:

Supplied:
3” Horizontal Copper Boiler P/N 4059
3” Burner Kit P/N 4016
1-1/2“ Vertical Refillable Gas Tank P/N 4272
1-1/4” Exhaust Oil Separator P/N 4062
Refillable Gas Tank Adaptor- Long (95 mm) P/N 4025
Screws/Bolts for Securing Components to Mounting Tray
Connecting piping for all components.
Possible fittings for steam connections to the engine if discussed at time of ordering.
Wood lagging, brass binding strips and instructions for lagging the boiler.

Not supplied:
Engine
Whistle with fittings: Please order it as a separate item The cost of installation is included in the price
Mounting Screws for fixing tray into the boat

Dimensions:
Mounting tray 100 x 255 mm with 100 x 75 to 100 mm engine space.
Height to top of pressure gauge 150 mm (6”)
Height to top of stack 240 mm (9.5”)
Height to top of engine 85 mm ( 3.35”)
Weight 1960 gm
